PyOpenGL は、Python で OpenGL を使用するためのモジュールです。
ここでは、OpenGLを使用して2Dの描画をしてみます。
#!env python
from OpenGL.GL import *
from OpenGL.GLUT import *
def draw():
glClearColor(1.0, 0.0, 0.0, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glFlush()
glutSwapBuffers()
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 1")
glutDisplayFunc(draw)
glutMainLoop()
from OpenGL.GL import *
from OpenGL.GLUT import *
glClearColor(1.0, 0.0, 0.0, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glFlush()
glutSwapBuffers()
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 1")
glutDisplayFunc(draw)
glutMainLoop()
#!env python
from OpenGL.GL import *
from OpenGL.GLUT import *
def draw():
glClearColor(0.0, 0.0, 1.0, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glBegin(GL_TRIANGLES)
glVertex(-1, -1)
glVertex(1, -1)
glVertex(0, 1)
glEnd()
glFlush()
glutSwapBuffers()
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 2")
glutDisplayFunc(draw)
glutMainLoop()
glBegin(GL_TRIANGLES)
glVertex(-1, -1)
glEnd()
#!env python
from OpenGL.GL import *
from OpenGL.GLUT import *
def resize(w, h):
glViewport(30, 50, w/2, h/2)
def draw():
glClearColor(0.0, 1.0, 0.0, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glBegin(GL_TRIANGLES)
glVertex(-1, -1)
glVertex(1, -1)
glVertex(0, 1)
glEnd()
glBegin(GL_LINES)
glVertex(-1, -1)
glVertex(1, -1)
glVertex(1, -1)
glVertex(1, 1)
glVertex(1, 1)
glVertex(-1, 1)
glVertex(-1, 1)
glVertex(-1, -1)
glEnd()
glFlush()
glutSwapBuffers()
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 3")
glutReshapeFunc(resize)
glutDisplayFunc(draw)
glutMainLoop()
glViewport(30, 50, w/2, h/2)
glutReshapeFunc(resize)
#!env python
from OpenGL.GL import *
from OpenGL.GLUT import *
def draw():
glClearColor(0.0, 0.5, 0.5, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glBegin(GL_TRIANGLES)
glVertex(-1, -1)
glVertex(1, -1)
glVertex(0, 1)
glEnd()
glFlush()
glutSwapBuffers()
def resize(w, h):
glViewport(0, 0, w, h)
def mouse(button, state, x, y):
if button == GLUT_LEFT_BUTTON:
print "left button",
elif button == GLUT_MIDDLE_BUTTON:
print "middle button",
elif button == GLUT_RIGHT_BUTTON:
print "right button",
else:
print "unknown button:", button,
if state == GLUT_DOWN:
print "down mouse button",
elif state == GLUT_UP:
print "up mouse button",
else:
print "unknown state:", state,
print(x, y)
def motion(x, y):
print "drag:", x, y
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 4")
glutReshapeFunc(resize)
glutDisplayFunc(draw)
glutMouseFunc(mouse)
glutMotionFunc(motion)
glutMainLoop()
def mouse(button, state, x, y):
GLUT_LEFT_BUTTON
GLUT_MIDDLE_BUTTON
GLUT_RIGHT_BUTTON
GLUT_DOWN
GLUT_UP
def motion(x, y):
glutMouseFunc(mouse)
glutMotionFunc(motion)
#!env python
from OpenGL.GL import *
from OpenGL.GLUT import *
def draw():
glClearColor(0.0, 0.5, 0.5, 0.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glBegin(GL_TRIANGLES)
glVertex(-1, -1)
glVertex(1, -1)
glVertex(0, 1)
glEnd()
glFlush()
glutSwapBuffers()
def resize(w, h):
glViewport(0, 0, w, h)
def mouse(button, state, x, y):
if button == GLUT_LEFT_BUTTON:
print "left button",
elif button == GLUT_MIDDLE_BUTTON:
print "middle button",
elif button == GLUT_RIGHT_BUTTON:
print "right button",
else:
print "unknown button:", button,
if state == GLUT_DOWN:
print "down mouse button",
elif state == GLUT_UP:
print "up mouse button",
else:
print "unknown state:", state,
print(x, y)
def motion(x, y):
print "drag:", x, y
def keyboard(key, x, y):
if key == '\033':
sys.exit()
elif key == 'q':
sys.exit()
else:
print(key)
glutInit(sys.argv)
glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE | GLUT_DEPTH)
glutInitWindowSize(320, 240)
glutCreateWindow("PyOpenGL 5")
glutReshapeFunc(resize)
glutDisplayFunc(draw)
glutMouseFunc(mouse)
glutMotionFunc(motion)
glutKeyboardFunc(keyboard)
glutMainLoop()
def keyboard(key, x, y):
glutKeyboardFunc(keyboard)
